ODY-301-R06_Dim
Features
- Output voltage & Current of driver - 36-50V/50V-60V/1.1A-1.8A
- Input voltage range -140V-290V
- Over Voltage Trip - Above 290V
- Environmental conditions - 10°C to +55°C
- Total Harmonic Distortion (THD) - < 10%
- Power Factor (PF) - > 0.95
- Driver dimensions, enclosure & construction - 125mm x 62mm
- Insulation resistance - Measured at 500V
- High Voltage Capacity (HV) - 1.5KV
- Over Voltage Protection(440V ) - For 2Hrs.
- Short circuit protection - YES
- Surge Protection - At 4KV
- Reverse polarity protection - YES
- Isolation Protection - Upto 3.75KV
- Isolated/Non-Isolated - Isolated
